| B9433S24B |
| 1.
MODEL NUMBER |
B9433S24B |
| 2. CATEGORY |
DC Round
Blower |
| 3. FRAME SIZE |
94 x 94 x33 mm (3.7 x 3.7 x1.3 inch) |
| 4. RATED VOLTAGE |
24 VDC |
| 5. OPERATING VOLTAGE RANGE |
21.6 V ~ 26.4V |
| 6. START-UP VOLTAGE |
17 V / Min. |
| 7. RATED MOTOR SPEED |
2800 RPM |
| 8. AIR FLOW |
22.5 CFM (0.64
m3/Min.) |
| 9. STATIC PRESSURE |
14.3
mm/H2O (0.56 inch/H2O) |
| 10. RATED CURRENT |
0.38 Amp |
| 11.
RATED INPUT POWER |
9.12 Watts |
| 12. NOISE LEVEL |
46.6 dB(A) |
| 13. DIRECTION OF ROTATION |
Clockwise viewed
from front label |
| 14. OPERATING TEMPERATURE |
-10% ~ + 70% / 66% (RH) |
| 15. STORAGE TEMPERATURE |
-40% ~ + 75% / 66% (RH) |
| 16. BEARING SYSTEM |
BALL BEARING
|
| 17.LIFE EXPECTANCY |
70,000
Hrs |
| 18. SAFETY APPROVAL |
UL, CUL, TUV,
CE |
| 19. WEIGHT |
150 gm |
|
